30.0 kW GLOBIMIX/TEJA Model DDK-30-1,5/500-V Dissolver

Description

Used stainless steel GLOBIMIX/TEJA (Poland) vakuum dissolver model DDK-30-1,5/500-V. Stainless steel din 1.4301 mixing shaft with stainless steel toothed disc agitator diameter 450 mm driven by EL. Motor 30,0kW/3PH/400V/50HZ/IP55/1480rpm. Equipped by frequency convertor and then shaft rotates from 0 to 1500 rpm. The second mixing element type single anchor with teflon scraper. Annchor rotation 17 rpm, driven with el. motor. Hydraulically lifted arm. Can holding/fixing device included. Also includes local control panel and electrical switchboard. Height 2050 mm. Floor space approx. 3100 X 1600 mm. Technical documentation and CE declaration of conformity are supplied with machine. Included : 1x mixing can, 1 x vacuum pump, 3 x Sandpiper pump,
